產品詳情









【太康銀城陽光鍋爐】國家定點,B級鍋爐企業。銀城陽光鍋爐廠專注于燃?xì)忮仩t、天然氣鍋爐、燃油燃?xì)忮仩t等燃?xì)庹羝仩t、燃?xì)鉄崴仩t、燃?xì)忮仩t價格、燃?xì)忮仩t廠家、天然氣鍋爐廠家。
太康銀城陽光鍋爐有限公司
全國24小時銷售服務熱線:15890500999
電 話:0394—6777060
聯系人:劉經理 手機:15890500999
公司網址:shop1463072718480.1688.com
DZH10-1.25-T single steam boiler ancillary equipment list
|
Serial number |
Name of goods |
Specification model |
Company |
number |
remarks |
|
One |
Boiler main engine |
||||
|
⑴ |
Boiler main engine |
DZH10-1.25-T |
platb |
1 |
|
|
⑵ |
Chimney flue |
|
set |
1 |
|
|
Two |
Auxiliary |
|
|
||
|
⑴ |
Induced draft fan |
Y5-47No-6C |
platb |
1 |
18.5KW |
|
⑵ |
Blower |
4-72-4A |
platb |
1 |
5.5KW |
|
⑶ |
Electric control cabinet |
RF-Ⅱ |
platb |
1 |
|
|
⑷ |
Feed water pump |
|
platb |
1 |
7.5kw |
|
⑸ |
steam manifold |
φ325 |
platb |
1 |
|
|
⑹ |
a duster |
|
platb |
1 |
|
|
⑺ |
water treatment |
|
platb |
1 |
|
|
Three |
Valves and instruments |
|
|
||
|
⑴ |
Full swing spring safety valve |
A48H-1.6C PN1.6 DN50 |
piece |
2 |
1.2-1.6MPa |
|
⑵ |
Globe valve |
J41T-1.6 PN1.6 DN100 |
件 |
1 |
Main steam |
|
⑶ |
Globe valve |
J41T-1.6 PN1.6 DN40 |
件 |
1 |
Auxiliary steam |
|
⑷ |
Globe valve |
Z41H-1.6 PN1.6 DN40 |
件 |
1 |
water supply |
|
⑸ |
Drain valve |
Z44H-1.6 PN1.6 DN40 |
件 |
3 |
Sewage |
|
⑹ |
Three-way Stopcock |
X14A-1.6 PN1.6 DN15 |
件 |
2 |
pressure |
|
⑺ |
Pressure gauge |
Y-150 M20×1.5,2.5 level |
件 |
2 |
0-2.5MPa |
|
⑻ |
Plate water level gauge |
M350H PN1.6 DN25 |
件 |
2 |
L=350 |
|
⑼ |
UDZ-453A-G |
Water level alarm controller |
件 |
1 |
L=350 |
|
Serial number |
Name of goods |
Specification model |
Company |
number |
remarks |
|
Four |
List of drawings and technical documents |
|
|||
|
⑴ |
General layout of boiler |
DZH10-1.25-T |
Zhang |
1 |
|
|
⑵ |
Boiler body |
DZH10-1.25-T |
Zhang |
1 |
|
|
⑶ |
Pipeline instrument valve |
DZH10-1.25-T |
Zhang |
1 |
|
|
⑷ |
foundation |
DZH10-1.25-T |
Zhang |
1 |
|
|
⑸ |
Smoke duct |
DZH10-1.25-T |
Zhang |
1 |
|
|
⑹ |
Installation instructions |
Type DZH series |
share |
1 |
|
|
⑺ |
Summary table of strength calculation results |
DZH10-1.25-Ttype |
share |
1 |
WJ0940-3 |
|
⑻ |
Factory list of products |
DZH10-1.25-Ttype |
share |
1 |
|
|
⑼ |
Certificate of quality |
|
share |
1 |
|
|
⑽ |
Boiler product safety and quality supervision and inspection certificate |
|
share |
1 |
周口鍋檢所 |
|
⑾ |
Certificate of compliance |
φ325 |
set |
1 |
|
|
⑿ |
Cylinder drawing |
φ325 |
set |
1 |
|
|
⒀ |
Boiler sample |
HenanProvince, hot Feng Boiler Co., Ltd. |
set |
1 |
|
|
Six |
Equipment factory total price (RMB) |
660000 yuan (including freight invoice) |
|||
1, the list of the annex applicable to the company's design drawings delineated in the scope of use, the user if there are special requirements, ordering should be put forward in writing.
2, according to the contents of the list provided by suppliers, other users to bring their own, if there is bion to the supply contract shall prevail.



Taikang Yincheng sunshine Boiler Co. Ltd.
Contact: Liu manager
Cell phone: 15890500999
Telephone: 0394-6777060
Fax: 0394-6777060
Mailbox: 39291839@qq.com
URL: http://shop1463072718480.1688.com
Address: Industrial Zone, Taikang County, Henan Province
[Henan] Taikang Silver City Sunshine State designated B boiler, boiler enterprises. Taikang Silver City Sunshine boiler factory specialized in gas boiler. Natural gas boilers. Fuel oil and gas boiler and gas steam boiler. Gas fired hot water boiler. Gas conducting oil furnace. Gas hot blast stove. Organic carrier gas furnace. Gas vacuum boiler. Vertical gas burning boiler. Horizontal gas-fired boiler. The biomass to steam boiler. Biomass boiler. Biomass stove. Biomass of heat-conducting oil furnace
Scope of application: electric power, machinery, bllurgy, chemical industry, textile, paper, food, industry, heating, hot water, bath, heating, etc.
