HOT LINE INDICATOR
? Designed for both distribution and transmission use
? Both models verify line conditions/voltage prior to use with an audible signal plus flashing lights
? The audible signal is 90 decibels, and banks of red lights flash intermittently to warn the operator of
voltage potential
? Both units incorporate a single push button on-switch that is timer oriented and will automatically
shut the unit off after a period of inactivity
? Each time the Hot Line Indicator is turned on, each model will run through a pre-programmed test
cycle and a green pilot light will remain on, indicating the unit is operating properly
? The distribution model 6701 includes a wide range of pre-set voltage levels (600V, 2000V, 7000V,
11000V), which assist the operator in determining whether full line voltage or a lesser voltage is
present
? The transmission model is for voltage ranges from 69KV to 500KV
? Both units include 2” diameter hook for contacting conductor and switch gear. Each unit comes with
a universal fitting and must be attached to an approved hot stick or hot line tool before use.
? Includes carrying case
? Operates on 9-volt battery - also included
? Bushing adapters available for 6701. For URD applications.
![2013072555375981[1]](http://cbu01.alicdn.com/img/ibank/2013/664/060/1050060466_1086601265.jpg)
|
CAT NO |
DESCRIPTION |
LBS |
|
6701 |
0-46KV HOT LINE INDICATOR COMPLETE WITH CARRYING CASE, BATTERY, CONDUCTOR HOOK, OPERATING INSTRUCTIONS AND SAFETY GUIDE |
3.7 |
|
6701-1 |
SAME AS 6701 EXCEPT WITH A LARGER STORAGE CASE FOR STORING BUSHING ADAPTERS |
4.2 |
|
266 |
BUSHING ADAPTER FOR 15KV AND 25KV LOADBREAK BUSHING ALSO ADAPTS TO ELASTIMOLD 35KV BUSHINGS |
1.5 |
|
267 |
RTE 35KV BUSHING ADAPTER |
1.8 |
|
6780 |
69-500KV TRANSMISSION HOT LINE INDICATOR |
3.7 |
